Afikim SE - CHAPTER 5 - TROUBLESHOOTING AND FAULT REPAIR

ֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹ
21
CHAPTER 5 - TROUBLESHOOTING AND FAULT REPAIR
The following table provides troubleshooting and repair instructions for
symptoms encountered when operating the SE. It presents the best ways to
handle the faults. The table contains three columns:
The Symptom - describes the functional problem that results from the fault.
Probable Cause - lists all probable causes for the relevant symptom. The
probable causes are listed logically by order of probability: the first one is the
most probable.
Remedy - lists the action to be taken to solve the problem. The appropriate
remedy appears opposite each probable cause. These remedies should solve
the problem; if not, continue down the list to the next cause/remedy.
Remember: you may contact your dealer at any time for further professional
support.
No.
Symptom
Probable Causes
Remedy
1
Flat tire and unstable
driving.
 Low air pressure.
 Puncture.
 Pump to normal
pressure.
 Repair the punctured tire.
2
The Service LED
Flashed and the vehicle
does not move.
 Manual Release Lever
pushed forward.
 Controller Coded Fault.
 Pull Lever Backwards.
 Ask for technical
assistance.
3
The Service LED Flashed
and the vehicle moves
only at low speed.
 Electric column is at up.
 Lower column position.
4
Manual Mechanical
Brake Lever is fully
pressed but the vehicle
does not stop.
 Loose hand brake
mechanism.
 Brake Cable needs to be
tighten.
Ask your technician to tight
the Brake Cable.
5
The Key Switch is
turned to “ON”
(clockwise), but the
“ON” light does not
come on.
 Main fuse popped out.
 Reset fuse.
Note: Do not reset fuse
more than twice. If the
symptom recurs after
resetting the second time,
call the authorized dealer
for further technical
support.
