Afikim SE - GENERAL DESCRIPTION OF THE SE

ֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹֹ
7
CHAPTER 1 - GENERAL DESCRIPTION OF THE SE
Note: The numbers in parentheses refer to the parts illustrated on Figure 1.
Handlebars (2)
There are two separate and independently adjustable
handlebars, one of which houses the controls for the SE.
Your SE is delivered to you with right-hand controls. (Left-
hands controls can be ordered through your dealer).
NOTE : On the Double Seat model the left handlebar is
shorter to allow for easier steering by the driver with 2
people on board. For a single user two handlebars of the
same length can be supplied. Ask your dealer.
Headlight (3)
Charging
Socket (4)
The socket is used to connect the charger plug for
batteries charging.
Seat (6)
The Single SE Seat is equipped with folding armrests (1)
to allow convenient access to the Seat. The Seat itself can
be rotated. The upholstery may be removed for cleaning.
(A deluxe orthopedic adjustable Seat is also available. Ask
your dealer).
The Double SE Seat is equipped with folding armrests (1)
as in the Single Seat model and can be tilted to make
service more accessible.
It can also be supplied with a Canopy (10) for protection
from sun and light rain.
Fuses (5)
5A - Main Fuses 2x40A or 70/80A– Semi Automatic
5B - Light Fuse (3A) - Semi Automatic
5C - Charging Fuse 15A – Semi Automatic
Seat Rotation
Lever (7)
The Lever is used to swivel the Seat 45 degrees in either
direction, to ease the driver's access to the Seat.
Rear Basket (8)
(Optional for Single
Seat model and
standard for Double
Seat model)
For carrying parcels and personal effects. Maximum load
20 kg (44 lbs).
Serial No.
Serial Number and Manufacturer’s data are located on the
rear side of the main lamp, and of the back of rear tray.
Manual Release
Lever of
Electromagnetic
Brake (11)
Located under the seat at the rear right of the SE, the
Electromagnetic Brake Manual Release Lever allows free
movement of the SE. To release, simply pull the brake
lever as shown in the near label. To engage the brake,
push lever opposite.
When lever is released the vehicle can not be operated.
