5.3.11 Protection Parameters
Operation
33
IsoChk ON
GfciChk ON
EarthChk ON
V.max 0.0V
V.maxT 0.00S
V.min 0.0V
V.minT 0.00S
F.max 0.00Hz
F.maxT 0.00S
F.min 0.00Hz
F.minT 0.00S
ISO.min 0KΩ
T.conn 0S
T.Reconn 0S
RSSEN ON
1. Insulation resistance detection
2. Leakage current detection
3. Ground detection
4. Voltage upper limit
5. Voltage upper limit time
6. Voltage lower limit
7. Voltage lower limit time
8. Frequency upper limit
9. Frequency upper limit time
10. Frequency lower limit
11. Frequency lower limit time
12. Impedance lower limit
13. Internet time
14. Restart time
15. Restart enable
Run Param
* * * *
Operating parameters setting
5432
Note:
When modifying parameters, you need to pay attention to the unit.
