Installation
20
Note:
The Max. power load connects to EPS port should not
exceed the inverter's EPS Max. output power range.
Note:
The wiring terminals should be wrapped with insulation tape,
otherwise it will cause a short circuit and damage the inverter.
Step 2
Step 3
GRID EPS Load
Fix the AC wiring cover with cover screws
GRID EPS Load
