Afore AF5000W-LE - Technical Specification

01 02
Power
Module
Model
Number
of battery
Modules
Battery
System
Capacity
Battery Cell
Technology
Battery
System
Voltage
Operating
Voltage Range
Dimension (W*D*H) Net Weight
AF5000W
-LE
1 5.12kWh
Li-iron(LFP)
600*210*440(mm)
23.62*8.27*17.32(inch)
57.2kg
(126.1 lb)
2 10.24kWh
51.2V
600*210*740(mm)
23.62*8.27*29.13(inch)
106.9kg
(235.67 lb)
3 15.36kWh
45.6-56.2V
600*210*1040(mm)
23.62*8.27*40.94(inch)
156.6kg
(345.24 lb)
4
20.48kWh
600*
210*1340(mm)
23.62*8.27*52.76(inch)
206.3kg
(454.81 lb)
Scalability Installation
Depth of
Discharge
Battery
System
Charge
Current
(recommendl)
Battery
System
Charge
Current
(Max)
Battery
System
Discharge
Current
(recommend)
Battery
System
Discharge
Current
(Max)
Display Certficates
Max 15 in
parallel
Floor stand 90% 50A 100A 50A 100A
The
information
of the Battery,
such as
SOC,
battery
status
IEC62619 /
IEC61000 /
IEC62040 /
CE /
UN38.3
Communic
ation Port
Protection
Cla
ss
Charging
temperature
Discharge
temperature
Humidity
Max.
operating
altitude
Warranty/
Number
of cycles
Cooling
RS232,
RS485,
CAN
IP65
0°C~50°C
(32°F-122°F)
-20°C~55°C
(-4°F-122°F)
5%-95%
2000m
(6561,68ft.)
10 years/
6000 times/
80% DOD
Natural
convection
Battery Cell Capacity Configuration
Battery Module Dimensions
(W*D*H)
100Ah 1P16S
600*210*300(mm)
23.62*8.27*11.81 (inch)
Battery module capacity
Battery Module
Voltage
Battery Module
Weight
5.12kWh 51.2V 49.7kg (109.57 lb)
1. Technical Specication
Battery Base
dimensions
(W*D*H)
Battery Cover
dimensions
(W*D*H)
Battery Base
Weight
Battery Cover
Weight
600*210*90 (mm)
23.62*8.27*3.54 (inch)
600*210*50 (mm)
23.62*8.27*1.97 (inch)
5kg (11.02Ib) 2.5kg (5.51Ib)
AF5000W-LE
AF5000W-LE
