Single-Phase(One MPPT Tracker)
HNS1000TL-1 HNS1500TL-1 HNS2000TL-1 HNS2500TL-1
HNS3000TL-1 HNS3600TL-1
3.Installation
3.1 Package
Unpacking
On receiving the inverter, please check to make sure the packing and all of the
components are not missing or damaged. Please contact your dealer directly for
supports if there is any damage or missing components.
Package List
Open the package, please check the packing list shown as below.
Installation
04
No.
1
2
3
4
5
6
7
1
1
1
1
1
1
1
Solar inverter
User manual
Certificate of inspection
Installation diagram
Warranty card
Wall mounting bracket
GPRS/Wi-Fi Monitoring Module
8
9
10
11
12
13
1
3
3
1
1
1 set
AC connector
Plastic Expansion Tube
Tapping screw
Security screw
Screwdriver for security screw
DC plug connector
Qty Items No. Qty Items
6
2 3 4 5
1
7
8 9
10 11 12 13
MC
STOP !
MC
User
Manual
Certificate
of
inspection
Installation
diagram
Warranty
card
