Afore HNS7000TL Installation And Operation Manual

1. About This Manual
1.1 Scope of Validity
1.2 Target Group
1.3 System Diagram
This manual describes the installation, commissioning, operation and
maintenance of the following on-grid PV inverters produced by Afore New
Energy:
This manual is for qualified personnel. The tasks described in this manual must
only be performed by qualified personnel.
Single-Phase((Two MPPT Tracker)
HNS7000TL HNS8000TL HNS9000TL HNS10000TL
Please keep this manual stored carefully and accessible at any time.
About This Manual
01
The typical connection diagram for the entire PV system is on-grid.
PE
WIFI / RS485
Cloud server
Web APP
PV Inverter
Circuit Breaker
N
L
AC Grid
Surge Protective
Device
Circuit Breaker
Surge Protective
Device
DCA1+
DCA1-
PVA
PV Array
Circuit Breaker
Surge Protective
Device
DCB2+
DCB2-
PVB
PV Array
Circuit Breaker
Surge Protective
Device
DCB1+
DCB1-
PVB
PV Array

Afore HNS7000TL Specifications

General

Brand	Afore
Model	HNS7000TL
Category	Inverter
Language	English
