Installation
06
Inverter Terminals
HNS9000-10000TL
HNS7000-8000TL
3
6
1
2
4
5
No.
1
2
3
4
5
6
DC Switch
DC Connectors ( + ) For PV Strings
DC Connectors ( − ) For PV Strings
AC Connector
Zero-Injection (Optional)
Monitor Module
Items
