Afore SAPM-10KW User Manual

1. About This Manual
2. Parameter
Afore smart meter is an intelligent control device, which is designed for
grid-connected inverters. Its main function is to measure the generation and
consumption, transmit the data to the inverter through RS485 communication, to
ensure that the generated power of the inverter is less or equal to the user’s load.
Achieve the purpose of no power feed into the grid.
This manual describes the installation, operation and maintenance of the
following Afore Smart Meter.
About This Manual
01
Type
Power ( kW )
Max Power ( kW )
Accuracy ( % )
Rating voltage ( V )
Voltage Range ( V )
Rating Current ( A )
Max Current ( A )
Connection For Measurement ( Hz )
Type
TAPM-50KW
50
55
1
230/400
320-440
72.5
80
Direct Connect
TAPM-130KW
130
150
1
230/400
320-440
200(MAX 5000 )
220(MAX 5000)
Via CT(current transducers)
SAPM-10KW
10
18
1
230
184-253
50
80
Direct Connect
For Single-phase System Applica�on
SAPM-10kW
For Three-phase System Applica�on
TAPM-50kW, TAPM-130kW
Frequency Range ( Hz )
Grid Type
Communication
Dimmension (W,L,H , mm)
IP
Installation
45-65
L+N
RS485
36 x 98 x 65
45-65
3P+N
RS485
72 x 100 x 65
IP20
35mm Rail

Afore SAPM-10KW Specifications

General

Brand	Afore
Model	SAPM-10KW
Category	Measuring Instruments
Language	English
