Zero-injection Connection
02
a. Single-phase Smart Meter
b. Three-phase Smart Meter
1. CAT5/CAT6 cable should be used between smart meter and inverter
Maximum length of cable less than 300m
2. Meter connection on the inverter
The meter needs to be connected to the inverter’s Zero-injection
port (RJ45 terminal).
3. Zero-injection Connection
Note:
