Note: you just need to enter either the outer diameter in M11 or the peripheral in M10
Window for entering pipe wall thickness
You may skip the menu and enter inner diameter in M13 instead.
Window for entering the inner diameter of the pipe
If pipe outer diameter and wall thickness are enter correctly, the inner diameter will be
calculated automatically, thus no need to change anything in the window
Window for selecting pipe material
Standard pipe materials (no need to enter material sound speed ) include:
(0) carbon steel (1) stainless steel (2) cast iron (3) ductile iron (4) copper
(5) PVC (6) aluminum (7) asbestos (8) fiberglass
(9) other( need to enter material sound speed in M15)
Window for entering the pipe material speed, only for non-standard pipe materials
Window for selecting the liner material, select none for pipes without any liner.
Standard liner materials(no need to enter the liner sound speed) include:
(1) Tar Epoxy (2) Rubber (3) Mortar (4) Polypropylene (5) Polystryol
(6)Polystyrene (7) Polyester(8) Polyethylene (9) Ebonite (10) Teflon
(11) Other (need to enter liner sound speed in M17)
Window for entering the non-standard liner material speed.
Window for entering the liner thickness, if there is a liner
Window for entering the ABS thickness of the inside wall of the pipe
Window for selecting fluid type
For standard liquids(no need to enter fluid sound speed) include:
(0) Water (1) Sea Water (2) Kerosene
(3) Gasoline (4) Fuel oil (5) Crude Oil
(6) Propane at -45C (7) Butane at 0C
(8)Other liquids(need to enter sound speed in M21 and viscosity in M22) (9) Diesel Oil
(10)Caster Oil (11)Peanut Oil (12) #90 Gasoline (13) #93 Gasoline (14)
Alcohol (15) Hot water at 125C
Window for entering the sound speed of non- standard liquid, used only when option item
8 ‘Other’ is selected in M20
Window for entering the viscosity of the non-standard liquids, used only when option item
8 ‘Other’ is selected in M20
Window for selecting transducer type, There are 22 types as following
0.
Standard M (The middle size)
1.
Insertion Type C
2.
Standard S
3.
User Type
4.
Standard B
5.
Insertion Type B(45)
6.
Standrad L (The large size transducers)
7.
JH-Polysonics
8.
Standard-HS (small size transducer for Handheld flow meter)
