afx light 9BEAM-FX User Manual

EN27
www.afx-light.com
11
147----156 Effect 15
157----166 Effect 16
167----176 Effect 17
177----186 Effect 18
187----196 Effect 19
197----206 Effect 20
207----216 Effect 21
217----226 Effect 22
227----236 Effect 23
237----246 Effect 24
247----256 Effect 25
12 0----255 Effect speed from fast to slow
13
0----199 No Function
200----249 Whole Fixture Reset after 3s
250-255 Sound Control
44 channel denition table
Channel DMX Value Function
1 000 - 255 Pan route 0°---360°
2
0---15 No function
128---191 X clockwise unlimited rotate from fast to slow
191---255 X Anticlockwise unlimited rotate from slow to fast
3 0---255 Tilt 1 0°---185°
4 0---255 Tilt 2 0°---185°
5 0---255 Tilt 3 0°---185°
6 0---255 Total dimmer 0-------100%
7
0---9 No strobe
10---255 Strobe speed from slow to fast
8 0---255 LED 1 red dimming 0-------100%
9 0---255 LED 1 green dimming 0-------100%
10 0---255 LED 1 blue dimming 0-------100%
11 0---255 LED 1 white dimming 0-------100%
12 0---255 LED 2 red dimming 0-------100%
13 0---255 LED 2 green dimming 0-------100%
14 0---255 LED 2 blue dimming 0-------100%
15 0---255 LED 2 white dimming 0-------100%
…… …… ……
40 0---255 LED 9 red dimming 0-------100%
41 0---255 LED 9 green dimming 0-------100%
42 0---255 LED 9 blue dimming 0-------100%
43 0---255 LED 9 white dimming 0-------100%
44
0----199 No Function
200----249 Whole Fixture Reset after 3s
250-255 Sound Control
