PF3000 Cotton Yield Monitor
Display Items
Ag Leader Technology
March 2002
Introduction
The PF3000 has four display lines for viewing items. You can choose what
items you see on the display and the position that the items appear on the
display.
To change the display item on a display line you must select the line. The
four keys to the right of the display each select a display line. A rectangular
box surrounds the display line to show that that line is selected.
When the display line is selected the four menu items on the bottom change
and show items you can select for display. Press a key below a display item
to put a different display item in place of the selected display item. There
are more than four display items to choose for viewing. Press the bottom
LEFT or RIGHT ARROW keys to scroll to the right or left and view other
display items on the bottom.
When some display items (like swath) are selected, an up and down arrow
symbol will appear on the right of the display line. This indicates you can
change the setting of the item with the UP or DOWN ARROW keys. After
you have made the change you must press the key to the right of the display
line to deselect the line.
Selection
Box
To Next Page
