23
Taking care to protect your ngers with a glove in case
the bulb should shatter, unscrew the old bulb.
Screw in the new bulb clockwise and then screw the
bulb cover back on. Turn on the electricity supply and
check that the bulb now lights.
The oven door is misaligned
The bottom hinge of either oven door can be adjusted
to alter the angle of the door (Fig.6-3). Loosen the
bottom hinge xing screws and use the notch and a at
bladed screwdriver to move the position of the hinge to
set the hinge position (Fig.6-4).
Retighten the hinge screws.
ArtNo.320-000 en oor h n e a t ent 1
Fig.6-3
Eect of hinge adjustment – exagerrated for clarity
ArtNo.320-000 en oor hn e a t ent 2
Fig.6-4
Centreline of hinge pin
Oven door omitted for clarity
