The AGARO Stand Mixer, model Royal (Item no - 33554), is a versatile kitchen appliance designed for a variety of mixing tasks, including kneading, stirring, and whisking. It comes with a 2-year warranty, with an option to extend it by 3 months upon product registration.

Function Description

The stand mixer is primarily used for preparing various food mixtures. It features an output shaft where different utensils can be attached, a mixing bowl for holding ingredients, and a speed knob to control the mixing intensity. The appliance is equipped with a rise button that allows the arm to be lifted for easy access to the mixing bowl and for attaching/detaching accessories. It operates on a 220-240V~ 50-60Hz safety power socket.

Usage Features

Setting Up the Mixer:

Lifting the Arm: To lift the mixer arm, press the Rise button (2) downwards in the direction of the arrow. The arm will then move upwards.
Placing the Pot Cover: Position the pot cover (9) onto the main body of the mixer.
Attaching the Mixing Bowl: Place the mixing bowl (5) into its holding device. Turn the bowl clockwise until it securely locks into place.
Mounting Utensils: Select the appropriate utensil (Dough hook (6), Beater (8), or Whisk (7)) for your task. Insert the top of the utensil into the output shaft (1) and turn it anti-clockwise until it locks into place.
Adding Ingredients: Fill the mixing bowl with your ingredients. It's crucial not to overfill the machine; the maximum quantity of ingredients should not exceed 1.0Kg.
Lowering the Arm: Once ingredients are added, lower the arm by pressing the rise button (2) downwards.
Connecting to Power: Insert the mains plug into a properly installed 220-240V~ 50-60Hz safety power socket.

Operating the Mixer:

Speed Control: Switch on the machine using the speed knob (3). You can select a speed between 1 and 6, depending on the mixture's consistency and the desired outcome.
Pulse Operation: For short-interval kneading or pulse operation, turn the speed knob to the "PULSE" position. The switch must be held in this position for the desired interval length. Releasing the switch will automatically return it to the "0" position.
Stopping the Mixer: After kneading or stirring, once the mixture has formed a ball or reached the desired consistency, turn the speed knob (3) back to the "0" position. Then, remove the mains plug from the socket.
Removing Mixture: Press the rise button (2) downwards to raise the arm. The mixture can then be released from the utensil using a spatula and removed from the mixing bowl.
Removing Mixing Bowl: The mixing bowl can now be easily removed from its holding device.

Adjusting Levels and Using Utensils (for mixtures up to 0.9kg):

Dough Hook (6):
- Levels: 1-5
- Time (Min): 3-5
- Maximum: 585g flour and 315g water
- Operation Method: Run at speed 1 for 30 seconds, then speed 3 for 30 seconds, and finally speed 5 for 2 to 4 minutes to form a cluster.
Beater (8):
- Levels: 2-6
- Time (Min): 3-10
- Maximum: 400g flour and 500g water
- Operation Method: Run at speed 2 for 20 seconds, then speed 6 for more than 2 minutes and 40 seconds.
Whisk (7):
- Levels: 6-8
- Time (Min): 3-10
- Maximum: 3 egg whites (Minimum)
- Operation Method: Open to speed 8 and run for 3 minutes or more.

Important Note on Operation Time: For heavy mixtures, do not operate the machine for more than six minutes continuously. Allow it to cool down for at least ten minutes before resuming operation to prevent overheating and damage.

Maintenance Features

Cleaning:

Safety First: Always remove the mains lead from the socket before cleaning the appliance.
Motor Housing: Never immerse the main housing, which contains the motor, in water. Use only a damp rinsing cloth to clean the outside of the housing. Avoid using sharp or abrasive detergents.
Mixing Bowl and Mixing Equipment: The mixing bowl and mixing equipment (dough hook, beater, whisk) are not suitable for cleaning in a dishwasher. Exposure to high heat or caustic cleaners in a dishwasher can cause them to become misshapen or discolored. Components that have come into contact with food can be cleaned in soapy water. Ensure all parts are thoroughly dried before reassembling the device. After drying, it is recommended to apply a small quantity of vegetable oil to the screens.

Troubleshooting:

Machine Doesn't Work:
- Check if the plug is in good contact with the socket.
- Ensure the rise button springs back into place.
- If the machine has been running continuously for more than 6-10 minutes, allow the motor to cool down.
Noise in Mixing Bowl (Accessory Scrapes Bowl):
- Verify that the mixing bowl is properly installed.
- Check if the accessory is properly installed on the machine.
Pot Cover Doesn't Fit Mixing Bowl Properly:
- Ensure the pot cover is properly placed on the machine.
- Check if the mixing bowl is properly installed and locked correctly.
Machine Doesn't Work on Certain Speed:
- Verify that the mark on the speed knob corresponds to the speed silkscreen on the housing.
- Rotate the speed knob to "0" and then re-check if the machine works.
Movements When Machine is Working:
- Check if the anti-slip feet have fallen off.
- Ensure the machine is placed on a smooth and flat tabletop.
Rise Button Doesn't Spring Back After Installing Mixing Bowl and Pot Cover:
- Check if the pot cover is properly placed on the machine.
- Verify that the mixing bowl is properly installed.

General Cautions:

This appliance is designed exclusively for home use and is not suitable for commercial purposes.
Avoid using the appliance with wet hands. If the appliance becomes humid or wet, unplug it immediately.
When cleaning or when the appliance is not in use, always switch it off and pull the plug from the socket (pull on the plug itself, not the cable). Remove any attached accessories.

Children and Frail Individuals Safety:

Keep all packaging materials (plastic bags, boxes, polystyrene, etc.) out of reach of children to prevent suffocation.
Do not allow small children to play with the foil.
The appliance can be used by individuals with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, provided they have been given supervision or instruction concerning safe use and understand the associated hazards.
Always disconnect the appliance from the power supply if it is left unattended, and before assembling, disassembling, or cleaning.
Switch off the appliance and disconnect from the power supply before changing accessories or approaching any parts that move during use.

Agaro Royal - About the Product; Main Components and Standard Accessories
