5
1.3 Specifications
Recommended use 1,000 ft. (300 m) diameter
Leveling accuracy ± 1/8” at 100 ft.
(± 0.010%; ± 10 mm at 100 m)
Self-leveling Horizontal and vertical
Leveling range ± 10%
Rotation speed 0, 90, 150, 300, 450, 600 rpm
Scanning angle Variable, from 2 to 36°
Laser diode Visible 635 nm; <5mW Class 3R
Power 2 D size (LR20) alkaline batteries
or rechargeable batteries
Battery life 160 hours with alkaline batteries
40 hours with rechargeable batteries.
Charging time 15 hours
Remote detection 100 ft. (30 m) / 180°
Environmental Weatherproof
(rain and dust proof – IP64)
Weight 3 lbs. (1.5 kg)
Size 7.75’’x 8’’x 5.5’’ (19.5 x 21 x 14 cm)
4
Although the A510S/AGATEC 510 is very simple to use, we rec-
ommend that you read this manual before operating the laser.
1.1 Description
The A510S is an automatic visible laser that can be used for level-
ing, vertical alignment, plumb, and squaring. Applications include
installing suspended ceilings, partitions, and a variety of outdoor
alignment work.
The A510S laser has these advanced features:
• Automatic self-leveling in both horizontal and vertical modes
• Motorized mount speeds setup for ceilings and partitions
• Manual leveling in X and Y axes for dual slope setting (± 10%)
• Semi-automatic single axis slope setting (automatic leveling in X
and manual leveling in Y)
• Ability to match slope for inclined planes greater than 10%
• Choice of beams, including scanning and chalk line
• Square shot that’s left and right adjustable
• Easy electronic calibration
1.2 Safety
The A510S is a Class 3R laser, manufactured to comply with the
international rules of safety IEC 60825-1, 2001. Although the
power of the emission of the beam is less than 5mW in Class 3R,
the following cautions are recommended:
• Do not stare directly at the beam
• Do not set up the laser at eye level
1. General information
A. CDRH warning label for USA
CLASS 3R LASER PRODUCT
WAVE LENGTH 630-680 nm
MAX. OUTPUT POWER: 5mW
LASER LIGHT: AVOID DIRECT EYE EXPOSURE
CONFORMS TO IEC 60825-1; 2001
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR DEVIATIONS
PURSUANT TO LASER NOTICE NO. 50
DATED JULY 26, 2001
AGATEC, 2202 Redmond Road
Jacksonville, AR 72076
B. Aperture label
AVOID EXPOSURE. LASER LIGHT
IS EMITTED FROM THIS APERTURE
B
A
