General Information
01-4 79024230 A Rev.
ENGINE (Cont)
Number of Cylinders 3
Bore mm (inch) 86 (3.39) 87 (3.43)
Stroke mm (inch) 84 (3.30)
Engine Horsepower (Gross) 21.2 kWh (28.4 HP)
@ 2500 rpm
24.6 kW (33.0 HP) @ 2600 rpm
(Net) 20.6 kW (28.0 PS)
@ 2500 rpm
23.5 kW (32.0 PS) @ 2600 rpm
PTO Horsepower (Estimate) 22.3 HP @ 581 PTO RPM 25.9 HP @ 604 PTO RPM
Firing Order 1-3-2
Compression Ratio 21.7 to 1
Combustion chamber type Swirl type
Low Idle Speed rpm 930-970 980-1020
High Idle Speed rpm 2650-2750 2760-2860
Valve Clearance (Cold); Intake mm (inch) 0.35 (0.014)
Valve Clearance (Cold); Exhaust mm (inch) 0.35 (0.014)
Air Cleaner Single stage, dry element
Engine Cooling Liquid, forced circulation
Starting method Starter motor with pre-heater
Cold Starting Aid Glow plugs (3)
Fuel Diesel
TABLE 1
1528 / ST28A / MT255B
4WD
1531 / ST33A
4WD
