4450A EN 20060221 Introducing the CR 85-X
CR 85-X DIGITIZER
After the Digitizer has been switched on, the following screen is displayed:
The CR 85-X executes a self-test, initializes all the Digitizer components, goes through
a start-up procedure and checks for cassettes, image plates and images still to be
transmitted in the image queue. During this stage, the status indicator is red and
flashing.
If the CR 85-X has completed the self-test successfully, the CR 85-X enters the operator
mode and displays the main operator screen:
The status indicator is constant green. The CR 85-X is ready for use.
If the CR 85-X displays:
An error has occurred during the self-test. Refer to Chapter 3, ‘Advanced
operation (‘Key-operator mode’)’.
WAIT
Self test proceeding
READY
CR 85-X
ERROR
Self test failed
SERVICE XXXXX
