52
4450A EN 20060221Advanced operation (‘Key-operator mode’)
CR 85-X DIGITIZER
4 If an image plate is jammed in the post-scan unit, try to remove the jammed image plate
by pulling it carefully towards you.
If the access is too narrow, lift the jammed plate over the erase unit and remove it
through the upper section of the Digitizer.
5 Close the front doors.
The CR 85-X will restart automatically.
After start-up, the operator main screen is displayed.
Caution: If it is still not possible to remove the image plate, do not
dismantle the unit any further. Contact your local service organization.
