AGFA DRYSTAR 5302 5366 - Film Run

DD+DIS150.05E
Functional Description
DOCUMENT CONTROL NOTE:
The controlled version of this document resides on MedNet. Any printed copy of this document is uncontrolled.
3 Film Run
This section describes the film run through the printer.
536602ag.cdr
TH
1
Edition 1, Revision 1 DRYSTAR 5302 Chapter 2 / 7
06-2009 Type 5366/100 Agfa Company Confidential
2
3
Filmrun
lower tray
Pickup Unit
Rollers driven by
gearbox module
(1 to 5)
Drum
Cam drive
Output Rollers
Motor
Suspension drive
CDM
Vacuum Pump
Filmrun
upper tray
4
5
Figure 2: Filmrun through the printer
Description of one film cycle:
1. The vacuum pump starts.
Figure 3: Pump & Valves Module
