AGFA DX-D 400 - Page 7

DX- D 400
User Manual
0232F EN 20191213
iii
Section Page
4.6 Receptor Assembly (Table and Wall Stand) 79.............................
4.6.1 T ravel of the Receptor Assembly (Table and Wall Stand) 79..........
4.6.2 Receptors 81...................................................
4.6.3 T ray for Cassette Film or CR (Table or Wall Stand) 82...............
4.6.4 Fixed Receptor Assembly (Table or W all Stand) 83.................
4.6.5 Portable Receptor Assembly (Table or Wall Stand) 84...............
4.6.5.1 Portable Receptor Assembly with Rotating Tray 84...........
4.6.5.2 Portable Receptor Assembly with non-Rotating Tray 87.......
4.6.6 Grids 90.......................................................
4.6.7 Using and Maintaining the Digital Detector 91.......................
4.7 X-ray Beam Alignment with Respect to Patient 92..........................
5 DX- D TOUCH SCREEN CONSOLE 93........................................
5.1 Radiography and General Controls 96....................................
5.1.1 Power ON / OFF 96.............................................
5.1.2 Service Mode 96...............................................
5.1.3 Workstation Selection 97........................................
5.1.4 Focal Spot Indicator 98..........................................
5.1.5 Radiographic Parameters 99.....................................
5.2 Automatic Exposure Control (AEC) 103....................................
5.2.1 Rapid Termination 104............................................
5.3 Anatomical Programmer (APR) 105.......................................
5.4 Exposure Controls and Status Indicators 115...............................
5.5 Self-Diagnosis Indicators 116............................................
5.6 Heat Units 117.........................................................
5.7 Dosimetry (Optional) 117................................................
5.8 Error Codes 118........................................................
