DX- D 600
User Manual
0242F EN 20181218
165
SECTION 11 TECHNICAL SPECIFICATIONS
11.1 ENVIRONMENTAL REQUIREMENTS
ATMOSPHERIC PRESSURE (hPa) RELATIVE HUMIDITY (%) AMBIENT TEMPERATURE
MIN MAX MIN MAX MIN MAX
WORKING
700 hPa 1060 hPa 30% 75%
10
o
C(50
o
F) 35
o
C(95
o
F)
TRANSPORT & STORAGE
500 hPa 1060 hPa 10% 90%
-20
o
C(--4
o
F) 70
o
C (158
o
F)
11.2 X-RAY SYSTEM POSITIONERS
11.2.1 POWER LINE REQUIREMENTS
EQUIPMENT FREQUENCY VOLTAGE
MAX. PERMANENT
CURRENT
CEILING SUSPENSION 50/60 Hz 115 - 240 VAC 3.5 - 1.6 A
RAD TABLE 50/60 Hz 115 - 240 VAC 4-2A
RAD WALL STAND DR* 50/60 Hz 24 VDC 4A
* NOTE: Power Line for the RAD Wall Stand DR is supplied by the RAD Table in Double Panel Systems and by the Ceiling
Suspension in Single Panel Systems.
