DX- D 600
User Manual
0242F EN 20181218
166
11.2.2 INFORMATION RELATED TO RADIATION
Radiation Output Accuracy: C.V. (Coefficient of Variation) ≤0.05
(Reproducibility related to loading factors)
Maximum Symmetrical Radiation Field:
Measured at 75 kVp: 160 mm in “X” axis and 240 mm in “Y” axis.
Measured at 125 kVp: 160 mm in “X” axis and 240 mm in “Y” axis.
(Test performed at a distance from the Focal Spot of 1200 mm, in accordance with IEC 60806: 1984)
11.2.3 DIMENSIONS AND PRODUCT WEIGHT
E
Q
U
I
P
M
E
N
T
DIMENSIONS
W
E
I
G
H
T
EQUIPMENT
DEPTH WIDTH HEIGHT
WEIGHT
RAD TABLE
868 mm
(34.17”)
2200 mm
(86.61”)
580 mm (22.83”) min.
920 mm (36.22”) max.
261 Kg
(575.4 lbs)
RAD WALL STAND
(w/o DR Detector)
637 mm
(25”)
518 mm
(20.39”)
2240 mm
(88.1”)
193 Kg
(425.48 lbs)
CEILING SUSPENSION WEIGHT Kg. lbs.
T OTAL WITHOUT CEILING RAILS SYSTEM 207.4 457.23
2 LONGITUDINAL RAILS (6.0 m) 43.2 95.24
BRIDGE OR TRANSVERSE RAILS (3.5 m) 31.7 69.88
CABLE SUPPORT RAIL (6.0 m) 5 11.02
T OTAL WITH CEILING RAILS SYSTEM 287.3 633.39
