DX- D 600
User Manual
0242F EN 20181218
29
Illustration 2-2
Radiographic Examination on the RAD Table
SIGNIFICANT ZONE OF OCCUPANCY
ATFRONTSIDEOFTHERADTABLE
SIGNIFICANT ZONE OF OCCUPANCY
AT THE RIGHT SIDE OF THE RAD TABLE
(CATHODE)
SIGNIFICANT ZONE OF OCCUPANCY
AT THE LEFT SIDE OF THE RAD TABLE
(ANODE)
RAD TABLE
S3
S4
S5
Focal Spot
X-ray Tube
S = SIGNIFICANT ZONE OF OCCUPANCY
MINIMUM AREA 60 x 60 cm
MINIMUM HEIGHT ABOVE THE FLOOR 200 cm
SID 100 cm
Phantom
X--Ray Receptor
Patient Support
RAD Table
S
Focal Spot
Focal Spot
S
50 cm
Dosimeter
X-ray T ube
S6
SIGNIFICANT ZONE OF OCCUPANCY
AT BACK SIDE OF THE RAD TABLE
