AGFA DX-D 600 - Page 41

DX- D 600
User Manual
0242F EN 20181218
33
Illustration 2-5
Distribution of Stray Radiation within the Receptor in Horizontal Front Side Position (S3)
HEIGHT (cm)
STRAY RADIATION (μGy/h))
0
20
40
60
80
100
120
140
160
180
200
0 10000 20000 30000 40000
S3 SID 50 cm
S3 SID 100 cm
SIGNIFICANT ZONE OF OCCUPANCY
AT THE FRONT OF THE RAD TABLE
RAD TABLE
S3
Focal Spot
X-ray Tube
