DX- D 600
User Manual
0242F EN 20181218
35
Illustration 2-7
Distribution of Stray Radiation with the Receptor in Horizontal Right Side Position (S5)
HEIGHT (cm)
STRAY RADIATION (μGy/h)
0
20
40
60
80
100
120
140
160
180
200
0 10000 20000 30000 40000
S5 SID 50 cm
S5 SID 100 cm
SIGNIFICANT ZONE OF OCCUPANCY
ON THE RIGHT OF THE RAD TABLE
(CATHODE)
RAD TABLE
S5
Focal Spot
X-ray Tube
