DX- D 600
User Manual
0242F EN 20181218
68
4.2 CEILING SUSPENSION MOVEMENTS
MONITOR THE EQUIPMENT MOVEMENTS WITH SPECIAL
CARE. AVOID ANY IMPACT OF THE SYSTEM ON FLOOR,
WALLS, OR OTHER ELEMENTS IN THE ROOM. IT MAY
CAUSE SERIOUS DAMAGE TO THE EQUIPMENT.
MONITOR WITH SPECIAL CARE THE PATIENT POSITION
(HANDS, FEET, FINGERS, ETC.) TO AVOID INJURY TO
PATIENT CAUSED BY UNIT MOVEMENTS. PATIENT HANDS
MUST BE KEPT AWAY FROM MOBILE COMPONENTS OF
THE UNIT.
INTRAVENOUS TUBING, CATHETERS AND OTHER PATIENT
CONNECTED LINES SHOULD BE ROUTED A WAY FROM
MOVING EQUIPMENT.
USE THE CONTROL CONSOLE WHEEL TO CONTROL AND
DRIVE THE UNIT MOVEMENT S, NEVER PUSH DIRECTLY ON
THE EQUIPMENT.
THE TELESCOPIC COLUMN MOVES UP AND DOWN
CREATING PINCH POINT AREAS. FOLLOWING
ILLUSTRATION INDICATES DANGEROUS LOCATIONS
WHERE PATIENT OR OPERATOR CAN BE INJURED OR
PINCHED. PLEASE PAY ATTENTION THAT NEITHER THE
PATIENT NOR OPERATOR GET PINCHED OR HURT IN
THESE AREAS.
Illustration 4-10
Potential Pinch Points
