SEMI-AUTOMATIC CEIL ING SUSPENSION WI TH RAD TABLE
In Semi-automatic Systems the Auto-tracking movement is available only in the
Vertical direction, by default.
The DR Detector of the Semi-automatic Table is not motorized, so
it cannot be controlled and tracked longitudinally by the Ceiling
Suspension.
The RAD Table is always the Master equipment and the Ceiling Suspension is
the Slave.
Proceed as indicated for manually operated Auto-tracking:
1. Press the AUTO-TRACKING control of the Console (or Remote Control
if available) to activate the function, the background is in yellow when
activated.
2. Move manually the Table (refer to Illustration 4- 25). Step and hold the
RAISE or LOWER Control Pedal to move UP/DOWN the DR Detector.
The Ceiling Suspension tracks vertically its movement in all cases. The
SID remains constant in all cases.
3. Step and hold the pedal until the Slave equipment arrives to the final
position and is aligned with the Master Equipment.
4. In case the brake button is released before finishing the Auto-tracking
movement, it gets aborted. Once the brake button or pedal is pressed
again, the Slave equipment gets aligned with the Master equipment at
the default SID.
