9. Press the <Select> key to save the new values to the sensor. The display will indicate;
10. Once the configuration has been saved the display will indicate;
11. Press the <Back> key to exit sensor configuration.
12. To verify if the configured parameters written correctly, exit menu to top level, and run
the function from step 1, and read the parameters out, and check its value.
The parameters that can be configured are fully described in the Technical Manuals for the
individual sensors. If “Config to Recalibrate” is selected for mCP001, the sensor will be
recalibrated after “Configuration Saved” is pressed, and the other parameters will not be
affected by the calibration. It is very important not to press any buttons when the calibration is
confirmed and wait till both red and green LED will go off. Calibrated proximity data, and
calibrated temperature can be review in this configuration menu for the mCP001 sensor.
3.5.2 Configuration of digital grain cable
To connect the grain cable special cable adapter must be used, CMC part number of that
adapter is 12077.
1. Select “Sensor Config” from the main menu;
2. The display will indicate:
3. Once connected, the display will indicate;
4. Once the information was read the tester will show number of sensors on the cable and
manufacturer of the cable as shown;
