1159A 1GHz Active Differential Probe
Calibration Testing Procedures
Setup for CMRR at 500 MHz
File Name: 1159CAL4a
Probe Connected to CH4 1163A
CH1 Sensitivity 200 mV/div; 50
CH4 Sensitivity 200 mV/div; 50
Offset and Position CH1, CH2, CH3 and CH4 0 V
Measure Amplitude CH1
Timebase 1 nSec/div
Timebase Delay 0 Sec
Setup Acquisition Equivalent time: 64 averages
Trigger CH4; 0 V
Ω
Ω
Setup for CMRR at 500 MHz
File Name: 1159CAL4b
Probe Connected to CH1 1159A
Probe Connected to CH4 1163A
CH1 Sensitivity 20 mV/div
CH4 Sensitivity 200 mV/div; 50
Offset and Position CH1, CH2, CH3 and CH4 0 V offset
Measure Amplitude CH1
Timebase 1 nSec/div
Timebase Delay 0 Sec
Setup Acquisition Equivalent time: 16 averages
Trigger CH4; 0 V
Ω
