24
1159A 1GHz Active Differential Probe
Calibration Testing Procedures
Setup for CMRR at 1 GHz
File Name: 1159CAL5a
Probe Connected to CH1 None
Probe Connected to CH4 1163A
CH1 Sensitivity 200 mV/div; 50
CH4 Sensitivity 200 mV/div; 50
CH2, CH3, and CH4 Off
Offset and Position CH1, CH2, CH3 and CH4 0 V
Measure Amplitude CH1
Timebase 500 pSec/div
Timebase Delay 0 Sec
Setup Acquisition Equivalent time: 16 averages
Trigger CH4; 0 V
Ω
Ω
Setup for CMRR at 1 GHz
File Name: 1159CAL5b
Probe Connected to CH1 1159A
Probe Connected to CH4 1163A
CH1 Sensitivity 50 mV/div
CH4 Sensitivity 200 mV/div; 50
CH2, CH3, and CH4 Off
Offset and Position CH1, CH2, CH3 and CH4 0 V
Measure Amplitude CH1
Timebase 500 pSec/div
Timebase Delay 0 Sec
Setup Acquisition Equivalent time: 16 averages
Trigger CH4; 0 V
Ω
