Agilent Technologies 34411A Datasheet

3
Accuracy Specifications ± (% of reading + % of range)
1
Function Range
3
Frequency, 24 Hour
2
90 Day 1 Year Temperature
Coefficient/°C
Test Current or Tcal ± 1 °C Tcal ± 5 °C Tcal ± 5 °C 0 °C to (Tcal -5 °C)
Burden Voltage (Tcal +5 °C) to 55 °C
DC Voltage 100.0000 mV 0.0030 + 0.0030 0.0040 + 0.0035 0.0050 + 0.0035 0.0005 + 0.0005
1.000000 V 0.0020 + 0.0006 0.0030 + 0.0007 0.0035 + 0.0007 0.0005 + 0.0001
10.00000 V 0.0015 + 0.0004 0.0020 + 0.0005 0.0030 + 0.0005 0.0005 + 0.0001
100.0000 V 0.0020 + 0.0006 0.0035 + 0.0006 0.0040 + 0.0006 0.0005 + 0.0001
1000.000 V
4
0.0020 + 0.0006 0.0035 + 0.0006 0.0040 + 0.0006 0.0005 + 0.0001
True RMS 100.0000 mV 3 Hz – 5 Hz 0.50 + 0.02 0.50 + 0.03 0.50 + 0.03 0.010 + 0.003
AC Voltage
5
to 750.000 V 5 Hz – 10 Hz 0.10 + 0.02 0.10 + 0.03 0.10 + 0.03 0.008 + 0.003
10 Hz – 20 kHz 0.02 + 0.02 0.05 + 0.03 0.06 + 0.03 0.005 + 0.003
20 kHz – 50 kHz 0.05 + 0.04 0.09 + 0.05 0.10 + 0.05 0.010 + 0.005
50 kHz – 100 kHz 0.20 + 0.08 0.30 + 0.08 0.40 + 0.08 0.020 + 0.008
100 kHz – 300 kHz 1.00 + 0.50 1.20 + 0.50 1.20 + 0.50 0.120 + 0.020
Resistance
6
100.0000 Ω 1 mA 0.0030 + 0.0030 0.008 + 0.004 0.010 + 0.004 0.0006 + 0.0005
1.000000 k Ω 1 mA 0.0020 + 0.0005 0.007 + 0.001 0.010 + 0.001 0.0006 + 0.0001
10.00000 k Ω 100 µA 0.0020 + 0.0005 0.007 + 0.001 0.010 + 0.001 0.0006 + 0.0001
100.0000 k Ω 10 µA 0.0020 + 0.0005 0.007 + 0.001 0.010 + 0.001 0.0006 + 0.0001
1.000000 M Ω 5 µA 0.0020 + 0.0010 0.010 + 0.001 0.012 + 0.001 0.0010 + 0.0002
10.00000 M Ω 500 nA 0.0100 + 0.0010 0.030 + 0.001 0.040 + 0.001 0.0030 + 0.0004
100.0000 M Ω 500 nA || 10 M Ω 0.200 + 0.001 0.600 + 0.001 0.800 + 0.001 0.1000 + 0.0001
1.000000 G Ω 500 nA || 10 M Ω 2.000 + 0.001 6.000 + 0.001 8.000 + 0.001 1.0000 + 0.0001
DC Current 100.0000 µA < 0.03 V 0.010 + 0.020 0.040 + 0.025 0.050 + 0.025 0.0020 + 0.0030
1.000000 mA < 0.3 V 0.007 + 0.006 0.030 + 0.006 0.050 + 0.006 0.0020 + 0.0005
10.00000 mA < 0.03 V 0.007 + 0.020 0.030 + 0.020 0.050 + 0.020 0.0020 + 0.0020
100.0000 mA < 0.3 V 0.010 + 0.004 0.030 + 0.005 0.050 + 0.005 0.0020 + 0.0005
1.000000 A < 0.8 V 0.050 + 0.006 0.080 + 0.010 0.100 + 0.010 0.0050 + 0.0010
3.000000 A < 2.0 V 0.100 + 0.020 0.120 + 0.020 0.150 + 0.020 0.0050 + 0.0020
True RMS 100.0000 µA to 3 Hz – 5 kHz 0.10 + 0.04 0.10 + 0.04 0.10 + 0.04 0.015 + 0.006
AC Current
7
3.00000 A 5 kHz – 10 kHz 0.20 + 0.04 0.20 + 0.04 0.20 + 0.04 0.030 + 0.006
Frequency 100 mV to 3 Hz – 5 Hz 0.070 + 0.000 0.070 + 0.000 0.070 + 0.000 0.005 + 0.000
or Period 750 V 5 Hz – 10 Hz 0.040 + 0.000 0.040 + 0.000 0.040 + 0.000 0.005 + 0.000
10 Hz – 40 Hz 0.020 + 0.000 0.020 + 0.000 0.020 + 0.000 0.001 + 0.000
40 Hz – 300 kHz 0.005 + 0.000 0.006 + 0.000 0.007 + 0.000 0.001 + 0.000
Capacitance
8
1.0000 nF 500 nA 0.50 + 0.50 0.50 + 0.50 0.50 + 0.50 0.05 + 0.05
10.000 nF 1 µA 0.40 + 0.10 0.40 + 0.10 0.40 + 0.10 0.05 + 0.01
100.00 nF 10 µA 0.40 + 0.10 0.40 + 0.10 0.40 + 0.10 0.01 + 0.01
1.0000 µF 10 µA 0.40 + 0.10 0.40 + 0.10 0.40 + 0.10 0.01 + 0.01
10.000 µF 100 µA 0.40 + 0.10 0.40 + 0.10 0.40 + 0.10 0.01 + 0.01
Temperature
9
RTD
-200 °C to 600 °C 0.06 °C 0.06 °C 0.06 °C 0.003 °C
Thermistor -80 °C to 150 °C 0.08 °C 0.08 °C 0.08 °C 0.002 °C
Continuity 1000.0
Ω 1 mA 0.002 + 0.010 0.008 + 0.020 0.010 + 0.020 0.0010 + 0.0020
Diode Test
10
1.0000 V 1 mA 0.002 + 0.010 0.008 + 0.020 0.010 + 0.020 0.0010 + 0.0020
1
Specifications are for 90 minute warm-up and 100 PLC.
2
Relative to calibration standards.
3
20% overrange on all ranges, except DCV 1000 V, ACV 750 V, DCI and ACI 3 A ranges.
4
For each additional volt over ± 500 V add 0.02 mV of error.
5
Specifications are for sinewave input > 0.3% of range and > 1 mV
rms
. Add 30 µV error for frequencies below 1 kHz.
750 VAC range limited to 8 x 10
7
Volts-Hz. For each additional volt over 300 V
rms
add 0.7 mV
rms
of error.
6
Specifications are for 4-wire resistance measurements, or 2-wire using Math Null.
Without Math Null, add 0.2
Ω additional error in 2-wire resistance measurements.
7
Specifications are for sinewave input > 1% of range and > 10 µArms. Frequencies > 5 kHz are typical
for all ranges. For the 3 A range (all frequencies) add 0.05% of reading + 0.02% of range to listed specifications.
8
Specifications are for 1-hour warm-up using Math Null. Additional errors may occur for non-film capacitors.
9
For total measurement accuracy, add temperature probe error.
10
Accuracy specifications are for the voltage measured at the input terminals only. 1 mA test current is typical.
Variation in the current source will create some variation in the voltage drop across a diode junction.
