Table of Contents
Topic Page Time
Lab 1
Viewing a motor start-up
sequence using a high defi nition display and deep memory
4 5 min.
Lab 2
Discovering an infrequent glitch with fast waveform update rates 6 5 min.
Lab 3
Viewing a complex “fast-slow” AM-modulated signal with a
high defi nition display and deep memory
8 5 min.
Take a few minutes to get to know the next-generation
portable oscilloscope – the Agilent 5000 Series. With
1 Mpts memory, an XGA-resolution display with 256
levels of intensity grading, and a fast 100,000 wfms/s
update rate, the new 5000 Series will show you more
than what you thought possible for a portable
oscilloscope.
If you would like to go further, feel free to evaluate the
same signals on the oscilloscope you are using today
with the comparative procedures inside.
