Agilent Technologies 54624A Service Guide

7-6
Replaceable Parts
To order a replacement part
MP1 54801-47401 See Descr Knob - 12mm Flint Gray
(54621A/22A – 6 ea)
(54621D/22D/24A – 8 ea)
MP2 54801-47402 See Descr Knob - 18mm Flint Gray
(54621A/21D/22A/22D – 3 ea)
(54624A – 5 ea)
MP3 54622-43702 1 Intensity shaft
MP4 54622-43701 1 Power switch shaft
MP5 54622-41901 1 Front-panel keyboard keypad (54621A/22A)
MP5 54622-41903 1 Front-panel keyboard keypad (54621D/22D)
MP5 54624-41901 1 Front-panel keyboard keypad (54624A)
MP6 54622-41902 1 Front panel softkey keypad
MP7 54622-00101 1 Main Deck
MP8 54622-94304 1 Rear-panel Trig Out label (54621A/22A)
MP8 54624-94302 1 Rear-panel Trig Out/Ext Trig label (54621D/22D/24A)
MP9 54642-42201 1 Front panel (54621A/22A/24A)
MP9 54642-42202 1 Front panel (54621D/22D)
MP10 54622-09104 See Descr RFI Gasket (Front)
(54621D/22D – 1 ea)
(54621A/22A/24A – 2 ea)
MP11 54622-09105 1 RFI Gasket (Rear)
MP15 54622-94311 1 Non-UL rear-cabinet label
MP16 54621-94301 1 Front-panel label set (54621A)
MP16 54621-94302 1 Front-panel label set (54621D)
MP16 54622-94301 1 Front-panel label set (54622A)
MP16 54622-94302 1 Front-panel label (set 54622D)
MP16 54624-94301 1 Front-panel label set (54624A)
MP17 54622-94303 1 Power specification rear-panel label
MP18 54642-64401 1 Cabinet assembly (with handle and feet installed)
MP20 54642-60600 1 RFI shield - keyboard
MP21 54642-60601 1 RFI shield- chassis side
MP23 54622-44901 1 Handle (part of MP18)
MP24 54624-27601 See Descr BNC
(54621D/22D – 2 ea)
(54621A/22A – 3 ea)
(54624A – 4 ea)
Reference
Designator
Agilent Part
Number
Qty Description
service.book Page 6 Wednesday, December 18, 2002 8:35 AM
