12
Table 2-1. Test Equipment Required
TYPE REQUIRED CHARACTERISTICS USE RECOMMENDED MODEL
Oscilloscope Sensitivity: 1 mV
Bandwidth: 20MHz & 100MHz
Input: differential, 50 Ω & 10MΩ
P,T Agilent 54504A
RMS Voltmeter True rms, 10MHz bandwidth
Sensitivity: 1 mV Accuracy: 5%
P Agilent 3400B
Logic Pulser 4.5 to 5.5Vdc @ 35mA T Agilent 546A
Multimeter Resolution: 100nV
Accuracy: 0.0035%, 6½ digit
P,C,T Agilent 3458A
Signature Analyzer -- T Agilent 5004A
GPIB Controller Full GPIB capabilities C,T,P HP Series, 200/300
Current Probe No saturation at 100A
Bandwidth: 20Hz to 15MHz
P Tek P6303 Probe
AM503 Amp
TM500 Power Module
Electronic Load 6030A 200 V/5 A P,C 6050A & 60503A (4)
60 V/17A 6050A & 60503A (4)
6031A 20 V/50 A 6050A & 60504A (2)
7 V/120 A 6050A & 60504A (2)
6032A 60 V/17.5 A 6050A & 60504A (2)
20 V/50 A 6050A & 60504A (2)
6035A 500 V/2 A
200 V/5 A
Power Resistor 250Ω 1% 1KW
6050A & 60503A (4)
Current Shunt
0.1Ω/0.04%/15A/25W
P,C Guildline 9230/15
0.01Ω/0.04%/100A/100W
Guildline 9230/100
0.001Ω/0.04%/300A/100W
Guildline 9230/300
Power Resistors*
6030A 3.5Ω/40Ω 1% 1000 W (min.)
P,C
6031A 0.069Ω/0.04Ω 1% 1000W (min.)
6032A 0.4Ω/3.5Ω 1% 1000W (min.)
6035A 40Ω/250Ω 1% 1000W (min.)
Calibration and Test
Resistors
Value: 100Ω, 5%, 1W
1Ω, 5%, ½W
1KΩ, 5%, ¼W
2KΩ, 0.01%, ¼W
C,T
Terminating
Resistors (2)
Value: 50Ω ±5%, noninductive
P
Blocking
Capacitors (2)
Value: 0.01µF, 100Vdc
P
Variable Voltage
Transformer
(autotransformer)
Adjustable from -13% to +6% of input
voltage range, 4KVA minimum
P,C
Isolation Transformer 4KVA minimum T
Common-mode
Toroidal Core
≥3.7µH/turn
2
≅23mm I.D.
P Ferrox-Cube
500T600-3C8,
Agilent 9170-0061
DC Power Supply Voltage range: 0-60Vdc
Current range: 0-3Adc
C,T Agilent 6024A
P = performance testing C = calibration adjustments T = troubleshooting
* Not required if using electronic load.
** Less accurate, and less expensive, current-monitor resistors can be used, but the accuracy to which current programming
and readback can be checked must be reduced accordingly.
