Agilent Technologies 6030A User Manual

90
Table 5-3. Replaceable Parts List (continued)
Ref. Desig Agilent Model Agilent Part Number Description
R139 all 0683-4725 res 4.7K 5% 1/4W
R140 all 0683-2025 res 2K 5% 1/4W
R141 all 0683-5135 res 51K 5% 1/4W
R142 all 0683-6835 res 68K 5% 1/4W
R143 all 0683-4725 res 4.7K 5% 1/4W
R144 all 0757-0415 res 475 1% 1/8W
R145 all 0683-1005 res 10 5% 1/4W
R146 all 0683-1035 res 10K 5% 1/4W
R147 all 0683-5115 res 510 5% 1/4W
R148 all 0757-0422 res 909 1% 1/8W
R149 all 0683-2025 res 2K 5% 1/4W
R150 6030A,35A 0754-0404 res 130 5% 1/4W
6031A,32A 0683-2715 res 270 5% 1/4W
R151 all 0683-4725 res 4.7K 5% 1/4W
R152 all 0757-0442 res 10K 1% 1/8W
R153 all 0757-0443 res 11K 1% 1/8W
R154 all 0757-0451 res 24.3K 1% 1/8W
R155 all 0757-0444 res 12.1K 1% 1/8W
R156 all 0683-4725 res 4.7K 5% 1/4W
R157 all 0683-1005 res 10 5% 1/4W
R158 all 0686-2005 res 20 5% 1/2W
R159,160 all 0680-6215 res 620 5% 1/2W
R161 all 0757-0283 res 2K 1% 1/8W
R162 all 0757-0442 res 10K 1% 1/8W
R163 all 0757-0283 res 2K 1% 1/8W
R164 all 0757-0434 res 3.65K 1% 1/8W
R165 all 0683-1035 res 10K 5% 1/4W
R166,167 all 0686-1315 res 130 5% 1/2W
R168 all 0683-1515 res 150 5% 1/4W
R169 all 0757-0124 res 39.2K 1% 1/8W
R170 all 0698-3136 res 17.8K 1% 1/8W
R171 all 0757-0280 res 1K 1% 1/8W
R172 all 0811-3174 res 0.07 5% 5W
R173 all 0683-2225 res 2.2K 5% 1/4W
R174 all 0683-3625 res 3.6K 5% 1/4W
R175 all 0683-1525 res 1.5K 5% 1/4W
R176 all 0683-2225 res 2.2K 5% 1/4W
R177 all 0683-0335 res 3.3 5% 1/4W
R178,179 all 0683-4725 res 4.7K 5% 1/4W
R180 all 0683-1045 res 100K 5% 1/4W
R182 all 0698-8827 res 1M 1% 1/8W
S1 all 3101-2097 switch (6) lA
U1-3 all 1826-0493 IC op amp Lo-bias Hi-impedance
U4,5 all 1826-0161 IC op amp quad general purpose
U6 all 1826-0346 IC op amp dual general purpose
U7 all 1826-0544 IC voltage reference 2.5V
U8 all 1826-0138 IC comparator quad
U9 all 1820-0935 IC counter binary CMOS
U10 all 1826-0065 IC comparator precision
U11 all 1826-0393 IC voltage regulator 1.2/37V
