68
Table 5-3. Agilent 6060B/6063B Parts List - Electrical (continued)
Reference
Designation
Models Agilent Part
Number
Description
C357 BOTH 0160-4820
CAP-FXD 1800pF
±5% 100V
C358 BOTH 0160-4829
CAP-FXD 680pF
±10% 100V
C370 BOTH 0160-4832
CAP-FXD 0.01
µF ±10% 100V
C501 BOTH 0180-2980
CAP-FXD 1000
µF ±20% 35V
C502 BOTH 0180-0376
CAP-FXD 0.47
µF ±10% 35V
C503 BOTH 0160-4835
CAP-FXD 0.1
µF ±10% 50V
C504 BOTH 0160-4787
CAP-FXD 22pF
±5% 100V
C506,507 BOTH 0160-4835
CAP-FXD 0.1
µF ±10% 50V
C551,552 BOTH 0160-4281
CAP-FXD 2200pF
±20% 250V
C553 BOTH 0160-4259
CAP-FXD 0.22
µF ±10% 0V
C554 BOTH 0180-3458
CAP-FXD 4700
µF +30% -10% 50V
C555 BOTH 0180-3298
CAP-FXD 2200
µF +30% -10% 50V
C556 BOTH 0180-4136
CAP-FXD 10uF
±10% 20V
CS57,558 BOTH 0180-3804
CAP-FXD 47uF
±20% 35V
C559 BOTH 0160-4787
CAP-FXD 22pF
±5% 100V
C560 BOTH 0180-4131
CAP-FXD 4.7
µF ±10% 35V
C561 BOTH 0180-0376
CAP-FXD 0.47
µF ±10% 35V
C562 BOTH 0160-4835
CAP-FXD 0.1
µF ±10% 50V
C601 BOTH 0160-5422
CAP-FXD 0.047
µF ±20% 50V
D9-13 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA DO-35
D14 BOTH 1901-0731 DIODE-PWR RECT 400V 1A
D16-28 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D29-32 BOTH 1901-0880 DIODE-GEN PRP 200MA
D35 BOTH 1901-0880 DIODE-GEN PRP 200MA
D36 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D202 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D204 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D300 BOTH 1901-0880 DIODE-GEN PRP 200MA
D303 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D304 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D306 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D308 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D310-313 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D501-504 BOTH 1901-0731 DIODE-PWR RECT 400V 1A
D505 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA
D551-555 BOTH 1901-0731 DIODE-PWR RECT 400V 1A
D556 BOTH 1901-0033 DIODE-GEN PRP 180V 200MA DO-35
Fl-8 BOTH 2110-0757 FUSE-SUBMINIATURE .063A 125V
F9-16 6060B 2110-0697 FUSE-SUBMINIATURE 15A 32 V
F9-16 6063B 2110-0685 FUSE-SUBMINIATURE 7A 125V
J201 BOTH 1252-0268 CONN-RECT MICRORBN 24-CKT 24-CONT
J202,203 BOTH 1251-4927 CONN-POST TYPE .100-PIN-SPCG 16-CONT
J553 BOTH 1252-0056 CONN-POST TYPE .156-PIN-SPCG 4-CONT
J554 BOTH 1252-0063 CONN-POST TYPE .100-PIN-SPCG 3-CONT
Ll-32 6063B 9170-1499 CORE-TOROID 5NH/TT
( 2 ea. 9170-1499 mounted on each end of R1-R8 sense
resistors)
