Table 5-3. Agilent 6060B/6063B Parts List - Electrical (continued)
Reference
Designation
Models Agilent Part
Number
Description
Ql,2 6060B 1858-0137 TRANSISTOR - FET ASSEMBLY
Ql,2 6063B 1855-0819 TRANSISTOR - FET ASSEMBLY
Q9 BOTH 1855-0386 TRANSISTOR J-FET 2N4392 N-CHAN D-MODE
Q10 BOTH 1854-0635 TRANSISTOR NPN SI
Q11 BOTH 1853-0281 TRANSISTOR PNP 2N2907A
Q12 BOTH 1858-0054 TRANSISTOR ARRAY
Q501 BOTH 1858-0054 TRANSISTOR ARRAY
Q551 BOTH 1858-0054 TRANSISTOR ARRAY
Rl-8 6060B 06060-80014
RESISTOR 0.050
±2% 6W
Rl-8 6063B 0811-3845
RESISTOR 0.3
±1% 3W
Rg-16 BOTH 0698-3430
RESISTOR 21.5
±1% .125W
R17-24 BOTH 0757-0441
RESISTOR 8.25K
±1% .125W
R25-32 BOTH 0757-0458
RESISTOR 51.1K
±1% .125W
R33-40 BOTH 0757-0442
RESISTOR 10K
±1% .125W
R41 BOTH 0757-0278
RESISTOR 1.78K
±1% .125W
R42 6060B 0698-5089
RESISTOR 33K
±1% .125W
R42 6063B 0698-3160
RESISTOR 31.6K
±1% .125W
R43 BOTH 1810-0316 NETWORK-RES 16-DIP 10.0K OHM X 8
R44 BOTH 0698-0084
RESISTOR 2.15K
±1% .125W
R45 BOTH 0757-0439
RESISTOR 6.81K
±1% .125W
R46 BOTH 0757-0438
RESISTOR 5.11K
±1% .125W
R47 BOTH 8159-0005 RESISTOR 0 CWM
R48 BOTH 0698-4479
RESISTOR 14K
±1% .125W
R49 BOTH 0698-0084
RESISTOR 2.15K
±1% .125W
R50 BOTH 0757-0458
RESISTOR 51.1K
±1% .125W
R53 6060B 8159-0005 RESISTOR 0 CWM
R53 6063B 0698-6620
RESISTOR 150K
±0.1% .125W
R54 6060B 0698-6629
RESISTOR 60K
±0.1% .125W
R54 6063B 0698-6332
RESISTOR 300K
±0.1% .125W
R55 6060B 0698-6360
RESISTOR 10K
±0.1% .125W
R55 6063B 0698-6533
RESISTOR 12.5K
±0.1% .125W
R56 6060B 0698-6360
RESISTOR 10K
±0.1% .125W
R56 6063B 0698-6533
RESISTOR 12.5K
±0.1% .125W
R57 BOTH 0757-0278
RESISTOR 1.78K
±1% .125W
R58 6060B 0698-3450
RESISTOR 42.2K
±1% .125W
R58 6063B 0698-4496
RESISTOR 45.3K
±1% .125W
R59 6060B 0757-0457
RESISTOR 47.5K
±1% .125W
R59 6063B 0698-4496
RESISTOR 45.3K
±1% .125W
R60 BOTH 0698-4457
RESISTOR 576
±1% .125W
R63 BOTH 0757-0458
RESISTOR 51.1K
±1% .125W
R64 BOTH 0757-0455
RESISTOR 36.5K
±1% .125W
R65 BOTH 0757-0438
RESISTOR 5.11K
±1% .125W
R66 BOTH 0698-0084
RESISTOR 2.15K
±1% .125W
R67 BOTH 0757-0427
RESISTOR 1.5K
±1% .125W
R68 BOTH 0698-6630
RESISTOR 20K
±0.1% .125W
R69 BOTH 0699-0620
RESISTOR 2.222K
±0.1% .1W
R70 BOTH 0757-0438
RESISTOR 5.11K
±1% .125W
