Agilent Technologies 6571A Service Manual

Replaceable Parts 113
Table 5-10. A6 output Filter Board Replaceable Parts (continued)
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
R910 ( Model specific)
6571A, 6671A,
6572A, 6672A
0698-3311
Resistor 51 Ω 5% 2W Mo
6573A, 6673A (Not used)
6574A, 6674A 0698-3642 Resistor 3K 5% 2W Mo
6575A, 6675A 0764-0034 Resistor 47K 5% 2W Mo
R911 (Model specific)
6571A, 6671A, 0699-1060
Resistor 0.05 Ω 1% 3W
6572A,6672A,
6573A, 6673A
0699-1075
Resistor 0.1 Ω 1% 3W
6574A, 6674A 0812-0019
Resistor 0.33 Ω 5% 3W PW
6575A, 6675A (Not used)
R912 (Model specific)
6571A, 6671A, 0699-1060
Resistor 0.05 Ω 1% 3W
6572A, 6672A,
6573A-6575A,
6673A-6675A
0699-1075
Resistor 0.1 Ω 1% 3W
R915 (Model specific)
6571A-6574A,
6671A-6674A
0757-0273 Resistor 3.01K 1%
6575A, 6675A 0698-3358 Resistor 4.02K 1%
R916 0698-0082
Resistor 464 Ω 1% 0.125W
R917 (Model specific)
6571A, 6671A,
6572A,6672A
(Not used)
6573A, 6673A 0764-0016 Resistor 1K 5% 2W Mo
6574A, 6674A (Not used)
6575A, 6675A 0698-3646 Resistor 12K 5% 2W Mo
R933 (Model specific)
6571A, 6671A (Not used)
6572A, 6672A 0698-0082
Resistor 464 Ω 1% 0.125W
6573A-6575A.
6673A-6675A
0698-0082 (Not used)
R934 (Model specific)
6571A-6574A,
6671A-6674A
(Not used)
6575A, 6675A 0698-0082
Resistor 464 Ω 1% 0.125W
R935 (Model specific)
6571A-6573A,
6671A-6673A
(Not used)
6574A, 6674A 0757-0290 Resistor 6.19K 1%
6575A, 6675A (Not used)
R936 (Model specific)
6571A, 6671A (Not used)
6572A-6575A,
6672A-6675A
0757-0451 Resistor 24.3K 1%
