Agilent Technologies 6571A Service Manual

116 Replaceable Parts
Table 5-11. A7 Snubber Board Replaceable Parts
.
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C901 (Model specific)
6571A-6574A,
6671A-6674A
(Not used)
6575A, 6675A 0764-0013 Capacitor 2200pF 1KV
C990 991 (Model specific)
6571A, 6671A 0160-5927
Capacitor 0.022µF 400V
6572A, 6672A 0160-6896
Capacitor 0.015µF 400V
6573A, 6673A 0160-6030
Capacitor 0.01µF 400V
6574A, 6575A, 6674A,
6675A
0160-6838 Capacitor 2200pF 1KV
R990,991 (Model specific)
6571A, 6671A,
572A, 6672A
0698-3601
Resistor 10 Ω 5% 2W MO
6572A, 6672A,
6573A, 6673A
0698-3614
Resistor 43 Ω 5% 2W MO
6574A, 6575A,
6674A, 6675A
0764-0013
Resistor 56 Ω 5% 2W MO
R992-R995 (Model specific)
6571A, 6671A (Not used)
6572A, 6672A,
6573A, 6673A
0698-3614
Resistor 43 Ω 5% 2W MO
6574A, 6575A,
6674A, 6675A
0764-0013
Resistor 56 Ω 5% 2W MO
R996-R999 (Model specific)
6571A-6574A,
6671A-6674A
(Not used)
6575A 6675A 0698-3635
Resistor 680 Ω 5% 2W MO
