Agilent Technologies 6571A Service Manual

28 Verification
Table 2-11. Performance Test Record for Agilent Model 6575A or 6675A
MODEL Agilent_____________
Report No.______________ Date_____________________
Test Description
Minimum
Spec.
Results
*
Maximum
Spec.
Constant Voltage Tests
Voltage Programming
and Readback
Low Voltage (0V) V
out
Front Panel Display Readback
-120mV
V
out
- 180mV
________mV
________mV
+120mV
V
out
+ 180mV
High Voltage (120V) V
out
Front Panel Display Readback
119.832V
V
out
- 240mV
_________V
_______mV
120.168V
V
out
+ 240mV
Load Effect
V
out
- 6.4mV _______mV V
out
+ 6.4mV
Source Effect
V
out
- 6.4mV _______mV V
out
+ 6.4mV
PARD (Ripple and Noise)
Peak-to-Peak
RMS
0
0
_______mV
_______mV
16mV
1.9mV
Transient Response Time
(at 900 μs)
0 _______mV 120mV
Constant Current Tests
Current Programming
and Readback
Low Current (0A) I
out
Front Panel Display Readback
-12mA
I
out
- 18mA
_______mA
_______mA
+12mA
I
out
+ 18mA
High Current (18A) I
out
Front Panel Display Readback
17.97A
I
out
- 36mA
_________A
_______mA
+18.03A
I
out
+ 36mA
Current Sink (2.5A) Display
Readback
I
sink
-20.5mA ________mA I
sink
+20.5mA
PARD (Ripple and Noise)
RMS
0 ________mA
12mA
Load Effect
I
out
- 1.9mA ________mA
I
out
+ 1.9mA
Source Effect
I
out
- 1.9mA ________mA
I
out
+ 1.9mA
*Enter your test results in this column.
