Replaceable Parts 95
Table 5-7. A3 FET Board Replaceable Parts
Ref. Desig. Agilent Part No. Description
ELECTRICAL PARTS
C201 0160-7505
Capacitor 7μF 200V 5%
C210, C211, C213, C214 0160-6838 Capacitor 2200pF 1000V 20%
C244, C245 1826-0138
Capacitor 0.1μF 400V 10%
L206, L208, L209, L211 9170-2122 Inductor, Core-toroid
J200 1252-0055 Connector Receptacle
J201 1251-7616 Connector Receptacle
J202 1252-2503 Connector Receptacle
Q201, Q202, Q203, Q204 1854-1784 Transistor MOSFFET VCE 600V IC 40A (matched set)
R201 0699-7384
Resistor 150 Ω 1% 30W
R213, R216, R220, R224 0699-7383
Resistor 75 Ω 1% 30W
T202 9100-4350 Transformer-Current
T204 06624-80091 Transformer-Pulse
-- 5188-4203 Cable assembly (J201)
-- 5188-4208 Cable assembly (J202)
MECHANICAL PARTS
-- 2110-1319 Fuse clip (qty 4)
-- 0380-1660 Spacer-round (qty 4)
-- 0515-0375 Screw M3x0.5 16mm (qty 4)
-- 0515-0664 Screw M3x0.5 12mm (qty 9)
-- 5188-4201 Thermal Pad (FET to heastsink)
-- 5188-4202 Insulator (PCA to heatsink)
-- 5002-2818 Heatsink
Note: All other parts are surface mounted and are not field repairable
