Dimensions
The physical dimensions of the power sensors differ in the model types. This is due
to the additional attenuation used to obtain the high power performance.
CAUTION Do not disassemble the power sensor. The 8480 series power sensors are static
sensitive and can be easily damaged.
8480 series, B-models information
The 25 W (+44 dBm) power sensor is a calibrated combination of a 30 dB, 25 W
attenuator assembly and a sensor assembly. The attenuator and sensor assemblies
are calibrated as a set and must be used together if specified accuracies are to be
obtained.
This combination is referred to as the power sensor.
Table 1-1 8480 Series Power Sensor Dimensions (including the RF Connector)
8480 series power
sensor models
Dimensions
A-models 8481A, 8482A and 8483A:
38 mm wide, 30 mm high, 105 mm long (1.5 in. x 1.2 in. x 4.1 in)
8485A and 8487A:
38 mm wide, 30 mm high, 95 mm long (1.5 in. x 1.25 in. x 3.75 in.)
B-models 83 mm x 114 mm x 248 mm (approx. 3.25 in. x 4.50 in. x 9.75 in.)
D-models 8481D and 8485D:
38 mm wide, 30 mm high, 102 mm long (1.5 in. x 1.2 in. x 4.02 in)
8487D:
38 mm wide, 30 mm high, 94 mm long (1.5 in. x 1.2 in. x 3.7 in)
H-models 38 mm wide, 30 mm high, 149 mm long (1.5 in. x 1.2 in. x 5.9 in)
