Introduction
Chapter 1 17
8487D
b
50 MHz to 50
GHz
50 MHz to
100 MHz: 1.19
100 MHz to 2 GHz:
1.15
2 GHz to 12.4 GHz:
1.20
12.4 GHz to 18
GHz: 1.29
18 GHz to 34 GHz:
1.37
34 GHz to 40 GHz:
1.61
40 GHz to 50 GHz:
1.89
-30 dBm to -20
dBm: ±2%
100 mW avg,
100 mW pk
10 W.µs / pulse
2.4 mm (m) Net: 0.2 kg
(0.38 lb)
Shipping:
0.5 kg (1.0 lb)
a. Negligible deviation except for those power ranges noted.
b. Includes 11708A 30 dB attenuator for calibrating against 0 dBm, 50 MHz power reference. The 11708A is factory set to
30 dB ±0.05 dB at 50 MHz, traceable to NIST. SWR < 1.05 at 50 MHz.
Table 1-8 High sensitivity sensors, 100 pW to 10 µW (–70 dBm to –20 dBm)
Model Frequency
Range
Maximum SWR
Power
Linearity
a
Maximum
Power
Connector
Type
Weight
