EPM Series Power Meter (E4418B) Modification
Appendix A54
The Material and Tools Required
The following material and tools are required for this modification:
• A T-15 torque screwdriver.
• A Razor blade or Craft Knife.
• Three 30 cm lengths of AWG 20 single core wire.
• Three screw-fit BNC Female connectors
(Agilent Part Number 1250-0118).
• A fine tip marker pen and adhesive labels.
• A 10-20 Watt pencil tip soldering iron.
• 60/40 0.8 mm rosin activated core solder wire.
• A Wire stripper.
• 25 lb/in Torque Wrench - Size 7/16 in. AF.
Impact on Warranty
NOTE Please be aware that doing this modification requires you to open the power sensor.
Therefore, as stated earlier, any attempt to disassemble the power sensor will void
the warranty.
