50 to 100 MHz < 1.19 (0.085)
0.1 to 4 GHz < 1.15 (0.070)
4 to 12 GHz < 1.19 (0.085)
12 to 18 GHz < 1.25 (0.112)
18 to 26.5 GHz < 1.29 (0.127)
8487D
50 to 100 MHz < 1.19 (0.085)
0.1 to 2 GHz < 1.15 (0.069)
2 to 12.4 GHz < 1.20 (0.091)
12.4 to 18 GHz < 1.29 (0.127)
18 to 34 GHz < 1.37 (0.156)
34 to 40 GHz < 1.61 (0.234)
40 to 45 GHz < 1.86 (0.301)
45 to 50 GHz < 1.89 (0.310)
Table 2-2 Power Sensor SWR and Reflection Coefficient
Frequency Maximum
SWR
(Reflection
Coefficient)
System SWR
Uncertainty
Performance
Limit (Rho -
System Rho
Uncertainty)
Actual
Measurement
