LCD Replacement Parts
Item
Description
8564EC
8565EC
Part
Number
Quantity
1
Screw-Machine w/Washer - Pan-HD - M3X0.5 - 6MM-LG x x 0515-0430 2
2
Screw-Machine w/Washer - Pan-HD - M3X0.5 - 8MM-LG x x 0515-0372 4
3
Rubber Grommet - Round - 0.219-IN-ID - 0.563-IN-OD - 0.062-IN-THK x x 0400-0333 4
4
Glass Filter x x 1000-1014 1
5
LCD Mount x x 5041-9632 1
6
LCD Backplate x x 5000-8314 1
7
LCD Driver Shield x x 5022-3667 1
8
Bracket - Board Mounting x x 5022-3665 1
9
Bracket - Attenuator Mounting x x 5022-3664 1
10
Screw-Machine - Flat-HD - M3X0.5 - 6MM-LG x x 0515-1227 4
11
Screw-Machine - Pan-HD - M2.5X0.45 - 6MM-LG x x 0515-0366 4
12
Screw-Machine - Flat-HD - M4X0.7 - 8MM-LG x x 0515-1101 2
13
Foam Pad - (Adheres to A17J5) x x 0340-1130 1
14
Screw-Machine w/Washer - Pan-HD - M3X0.5 - 14MM-LG x x 0515-0665 4
