Chapter 12 521
Replaceable Parts
Component-Level Information Packets
Component-Level Information Packets
Component-level information is available for selected instrument
assemblies. The information for each repairable assembly is provided in
the form of Component-Level Information Packets (CLIPs).
A CLIP packet consists of a parts list, component-location diagram, and
schematic diagram relating to a unique instrument assembly. An
Agilent Technologies part number is assigned to each CLIP packet.
When an instrument assembly part number changes, a new CLIP is
generated.
Ordering CLIPs
For ordering convenience, current CLIPs for a specific instrument are
combined into Component-Level Information binders. The current set
of CLIPs contains information supporting the instrument assemblies
manufactured at the time this manual was printed, plus a packet
containing general CLIP information.
A complete set of CLIPs can be obtained by ordering the 8590 Series
Analyzers Component-Level Repair Service Guide.
Updated or replacement CLIPs may be ordered through your local
Agilent Technologies Sales or Service office using the CLIP part
number provided in Table 12-2.
NOTE CLIPs may not be available for recently introduced assemblies.
