17-5
Mask Test Commands
COUNt:SAMPles?
negative margins. To determine a negative margin, increase the magnitude of the negative
margin until the number of margin hits goes to zero. All data acquired since mask margin
testing was enabled will be compared to the margin. Sampled points acquired before the mar-
gin was activated, that fall into the margin region, will also show up as mask hits. MASK
Returns the number of data points that failed the standard mask.
Returned Format [:MTESt:COUNt:HITS] <number_of_hits><NL>
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MTEST:COUNT:HITS? MARGin”
COUNt:SAMPles?
Query :MTESt:COUNt:SAMPles?
The query returns the total number of samples captured in the current mask test run. The
value 9.999E37 is returned if mask testing is not enabled.
Returned Format [:MTESt:COUNt:SAMPles] <number_of_samples><NL>
<number_of _samples> is the total number of samples for the current test run.
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MTEST:COUNT:SAMPLES?”
COUNt:WAVeforms?
Query :MTESt:COUNt:WAVeforms?
The query returns the total number of waveforms gathered in the current mask test run. The
value 9.999E37 is returned if mask testing is not enabled.
Returned Format [:MTESt:COUNt:WAVeforms] <number_of_waveforms><NL>
<number_of_ waveforms> is the total number of waveforms for the current test run.
Example 10 OUTPUT 707;”:SYSTEM:HEADER OFF”
20 OUTPUT 707;”:MTEST:COUNT:WAVEFORMS?”
DELete
Command :MTESt:DELete
This command clears the currently loaded mask. MTESt:DELete is the preferred command.
(See also MTESt:MASK:DELete.)
Example 10 OUTPUT 707;”:MTEST:DELETE”
EXIT
Command :MTESt:EXIT
This command terminates mask testing.
NOTE Compatibility with the Agilent 83480A/54750A. The :MTESt:TEST OFF command performs the
same function as :MTESt:EXIT and is provided for compatibility with the Agilent 83480A/54750A. For new
programs, use the :MTESt:EXIT command.
Example 10 OUTPUT 707;”:MTEST:EXIT”
