Measure Commands

AMPLitude:RINoise:DEF

Restrictions 86100C (software revision A.07.00 and above) with Jitter Mode including Advanced Ampli-

tude Analysis/RIN/Q-Factor application.

Example 10 OUTPUT 707;”:MEASURE:AMPLITUDE:RINOISE? OLEVel”

Returned Format [:MEASure:AMPLitude:RINoise] <value><NL>

AMPLitude:RINoise:DEF

Command MEASure:AMPLitude:RINoise:DEF {OMAMplitude | OLEVel}

Defines the type of RIN measurement performed. OLEVel specifies a RIN measurement that is

based on the one level. OMAMplitude specifies a RIN OMA measurement.

Restrictions 86100C (software revision A.07.00 and above) with Jitter Mode including Advanced Ampli-

tude Analysis/RIN/Q-Factor application.

Example 10 OUTPUT 707;”:MEASURE:AMPLITUDE:RINOISE:DEF OMAMplitude”

Query Returns the type of RIN measurement currently selected.

MEASure:AMPLitude:RINoise:DEF?

Returned Format [:MEASure:AMPLitude:RINoise:DEF] {OMAMplitude | OLEVel}<NL>

AMPLitude:RINoise:UNITs

Command MEASure:AMPLitude:RINoise:UNITs { DB | DBHZ }

Specifies the units for the Random Intensity Noise (RIN) measurement. The measurement is

only available for optical signals. Units of dB/Hz are only available when a reference filter is in

use.

Restrictions 86100C (software revision A.07.00 and above) with Jitter Mode including Advanced Ampli-

tude Analysis/RIN/Q-Factor application.

Example 10 OUTPUT 707;”:MEASURE:AMPLITUDE:RINOISE:UNITS DB”

Query MEASure:AMPLitude:RINoise:UNITs?

Returned Format [:MEASure:AMPLitude:RINoise:UNITs] { DB | DBHZ }<NL>

AMPLitude:RN?

Query MEASure:AMPLitude:RN? {ONE | ZERO}

Returns the random noise measurement for the specified logic level. Uses the current noise

and interference units.

Restrictions 86100C (software revision A.07.00 and above) with Jitter Mode including Advanced Ampli-

tude Analysis/RIN/Q-Factor application.

Example 10 OUTPUT 707;”:MEASURE:AMPLITUDE:RN? ONE”

Returned Format [:MEASure:AMPLitude:RN] <value><NL>

AMPLitude:RNSTabilize

Command MEASure:AMPLitude:RNSTabilize {ON | 1 | OFF | 0}

Turns the RN stabilization on or off.
